SK 3184800 Wall-mounted cooling unit Blue e+ S 1.0 kW

Giá bán: Liên hệ

SK Cooling unit Blue e+ S, wall-mounted, 1.0 kW, 110-240 V, 1~, 50-60 Hz, sheet steel, WHD: 400 x 950 x 196 mm

Tình trạng: Còn hàng

Bảo hành:

Địa chỉ

109 Đường N2, Khu dân cư Khang Điền, P. Long Trường, TP HCM, VN

HOTLINE

0917082400

Đặt mua ngay

Thông tin chi tiết
Thông tin bổ sung

CATEGORY	DETAILS
Total cooling output to DIN EN 14511	L35/L35: 1 kW (50/60 Hz) • L35/L50: 0.6 kW (50/60 Hz)
Cooling output (BTU/h)	L35/L35: 3,412 BTU/h (50/60 Hz) • L35/L50: 2,047 BTU/h (50/60 Hz)
Rated operating voltage	110–240 V, 1~, 50/60 Hz
Rated output	0.6 kW
Air throughput	External circuit: 680 m³/h • Internal circuit: 680 m³/h
Air throughput (CFM)	External circuit: 400.2 cfm • Internal circuit: 400.2 cfm
Energy efficiency ratio	EER (L35/L35): 2.4 (50/60 Hz)
Design	Wall-mounted
Dimensions	400 × 950 × 196 mm
Dimensions (inch)	15.7 × 37.4 × 7.72 ˝
Mounting cut-out	Width: 383 mm • Height: 929 mm
Mounting cut-out (inch)	Width: 15.1 ˝ • Height: 36.6 ˝
Protection category	Internal circuit: IP55
NEMA protection	UL Type 1 / UL Type 12
Refrigerant	R-513A / 0.31 kg
Global warming potential	GWP: 631 • CO₂e: 0.2 t
Refrigerant (lb.)	Quantity: 0.7 lb
Temperature control	e+ controller (factory setting +35 °C)
Operating temp range	-20 °C to +60 °C
Operating temp range (°F)	-4 °F to +140 °F
Storage temp range	-40 °C to +70 °C
Storage temp range (°F)	-40 °F to +158 °F
Refrigerant circuit range	3 °C to 60 °C
Heat pipe range	-20 °C to 45 °C
Setting range	20 °C to 50 °C
Setting range (°F)	68 °F to 122 °F
Rated power consumption	L35/L35: 0.42 kW (50/60 Hz) • L35/L50: 0.48 kW (50/60 Hz)
Permissible pressure	Max. 34 bar (493.1 PSI)
Packaging unit	1 pc
Weight	Net: 26.5 kg • Gross: 31.5 kg
Notes	Observe assembly instructions. Semi-outdoor use only. Voltage tolerance: 110 V -10% (99 V) / 240 V +10% (264 V).
