SK 3329600 Wall-Mounted Cooling Unit TopTherm Blue e 2.55 kW

Giá bán: Liên hệ

SK cooling unit Blue e, wall-mounted, 2.55 kW, 230 V, 1~, 50/60 Hz, Stainless steel, WHD: 400 x 1580 x 295 mm

Tình trạng: Còn hàng

Bảo hành:

Địa chỉ

109 Đường N2, Khu dân cư Khang Điền, P. Long Trường, TP HCM, VN

HOTLINE

0917082400

Đặt mua ngay

Thông số	Giá trị
Total cooling output (DIN EN 14511)	L35 L35: 2.55 kW (50 Hz), 2.6 kW (60 Hz) L35 L50: 1.8 kW (50 Hz & 60 Hz) (8,701 / 8,872 / 6,142 / 6,142 BTU/h)
Rated operating voltage	230 V, 1~, 50 Hz/60 Hz
Note on Model No.	Delivery times on request
Rated current max.	7.9 A (50 Hz), 10.1 A (60 Hz)
Start-up current (max.)	25 A (50 Hz), 22 A (60 Hz)
Air throughput (unimpeded air flow)	External circuit: 1,230 m³/h (724 cfm) Internal circuit: 1,230 m³/h (724 cfm)
Energy efficiency ratio (EER)	L35 L35: 2.11 (50 Hz), 1.7 (60 Hz)
Version	Wall-mounted
Dimensions	Width: 400 mm (15.7˝) Height: 1,580 mm (62.2˝) Depth: 295 mm (11.6˝)
Protection category (EN 60 529)	External circuit: IP 34 Internal circuit: IP 54
Protection category (NEMA)	UL Type 12
Refrigerant / cooling medium	Refrigerant: R-513A Quantity: 1.15 kg (2.5 lb.) GWP: 631 CO₂e: 0.73 t
Temperature control	e-Comfort Controller (factory setting +35 °C)
Operating temperature range	10 °C…55 °C (50 °F…131 °F)
Storage temperature range	-40 °C…70 °C (-40 °F…158 °F)
Setting range	20 °C…55 °C (68 °F…131 °F)
Rated power Pel	L35 L35: 1.21 kW (50 Hz), 1.53 kW (60 Hz) L35 L50: 1.41 kW (50 Hz), 1.8 kW (60 Hz)
Permissible operating pressure (p. max.)	28 bar (406.1 PSI)
Pre-fuse	Miniature circuit-breaker/fuse: 16 A
Packaging unit	1 pc(s)
Net weight	65.55 kg
Gross weight	69 kg
