SK 3335930 VX25 TopTherm Chiller 7.8/8.4 kW

Giá bán: Liên hệ

SK Chiller TopTherm, in a VX25 housing, 7.8/8.4 kW, 400 – 460 V, 3~, 50/60 Hz, WHD: 808 x 2238 x 608 mm

Tình trạng: Còn hàng

Bảo hành:

Địa chỉ

109 Đường N2, Khu dân cư Khang Điền, P. Long Trường, TP HCM, VN

HOTLINE

0917082400

Đặt mua ngay

Thông số	Giá trị
Total cooling output (DIN EN 14511 Tw18 / Tu35)	7.8 kW (50 Hz), 8.4 kW (60 Hz)
Air throughput (unimpeded air flow)	6,000 m³/h (50 Hz), 7,200 m³/h (60 Hz) 3,531.5 cfm (50 Hz), 4,237.8 cfm (60 Hz)
Rated operating voltage	400 V, 3~, 50 Hz 460 V, 3~, 60 Hz
Dimensions	Width: 808 mm (31.8˝) Height: 2,238 mm (88.1˝) Depth: 608 mm (23.9˝)
Note	Regular leak testing is not required by law
Noise pressure level	74.8 dB(A)
Temperature control	E-controller (factory setting +18 °C)
Operating temperature range	10 °C…43 °C (50 °F…109 °F)
Cooling medium temperature range	10 °C…25 °C (50 °F…77 °F)
Temperature hysteresis	± 1 K
Refrigerant / cooling medium	Refrigerant: R-513A Quantity: 1.6 kg (3.5 lb.) GWP: 631 CO₂e: 1.01 t
Pump pressure	2.7 bar (50 Hz), 4 bar (60 Hz)
Power consumption (cooling medium pump)	0.67 kW (50 Hz), 1.06 kW (60 Hz)
Volumetric flow (cooling medium)	23 l/min (50 Hz), 25 l/min (60 Hz)
Rated power Pel	4.72 kW (50 Hz), 6.2 kW (60 Hz)
Rated current max.	9.2 A (50 Hz), 9.5 A (60 Hz)
Refrigeration factor (EER)	2.3 (50 Hz, Tw18 / Tu35 DIN EN 14511)
Water connections	R 1″ internal thread
Number of cooling circuits	1
Tank	Material: Plastic PP Volume: 75 l
Operating weight	345 kg (760.6 lb.)
Packaging unit	1 pc(s)
Net weight	245 kg
Gross weight	253 kg
