SK 3486330 Wall-mounted air conditioner Blue e + Outdoor 2.0 kW

Giá bán: Liên hệ

SK cooling unit Blue e+, wall-mounted outdoor, 2.0 kW, 110-240 V, 1~, 380-480 V, 3~, 50-60 Hz, aluminum, WHD: 465 x 1640 x 260 mm

Tình trạng: Còn hàng

Bảo hành:

Địa chỉ

109 Đường N2, Khu dân cư Khang Điền, P. Long Trường, TP HCM, VN

HOTLINE

0917082400

Đặt mua ngay

Thông tin chi tiết
Thông tin bổ sung

CATEGORY	DETAILS
Total cooling output to DIN EN 14511	L35/L35: 2 kW (50/60 Hz) • L35/L50: 1.29 kW (50/60 Hz)
Cooling output (BTU/h)	L35/L35: 6,824 BTU/h (50/60 Hz) • L35/L50: 4,402 BTU/h (50/60 Hz)
Rated operating voltage	110–240 V, 1~, 50/60 Hz • 380–480 V, 3~, 50/60 Hz
Rated output	0.85 kW
Rated power consumption	L35/L35: 0.7 kW (50/60 Hz) • L35/L50: 0.68 kW (50/60 Hz)
Temperature control	e+ controller (factory setting +35 °C)
Dimensions	450 × 1,640 × 260 mm
Dimensions (inch)	17.7 × 64.6 × 10.2 ˝
Enclosure dimensions incl. sealing frame & designer cover	517 × 1,692 × 260 mm
Installation type	Universal installation (surface-mounting, partial internal installation, full internal installation)
Protection category (IEC 60 529)	With mounting frame: Internal circuit IP56 • Without mounting frame: Internal circuit IP54
NEMA protection	With mounting frame: UL Type 12/3R/4 • Without mounting frame: UL Type 12/3R
Air throughput	External circuit: 1,250 m³/h • Internal circuit: 1,250 m³/h
Air throughput (CFM)	External circuit: 735.7 cfm • Internal circuit: 735.7 cfm
Refrigerant	R-1234yf / 1.1 kg
Global warming potential	GWP: 0.5 • CO₂e: 0 t
Refrigerant (lb.)	Quantity: 2.4 lb
Energy efficiency ratio	EER (L35/L35): 2.86 (50/60 Hz)
Suitable for enclosure	Toptec
Suitable enclosure dimensions	Width: ≥ 800 mm • Height: ≥ 1,800 mm
Suitable enclosure dimensions (inch)	Width: ≥ 31.5 ˝ • Height: ≥ 70.9 ˝
Compatible Model No.	9782.828 / 9783.888
Setting range	20 °C to 50 °C
Setting range (°F)	68 °F to 122 °F
Operating temp range	-30 °C to +60 °C
Operating temp range (°F)	-22 °F to +140 °F
Refrigerant circuit range	3 °C to 60 °C
Heat pipe range	-30 °C to 45 °C
Storage temp range	-40 °C to +70 °C
Storage temp range (°F)	-40 °F to +158 °F
Permissible operating pressure	2.4
Noise pressure level	70 dB(A)
Packaging unit	1 pc
Weight	Net: 64 kg • Gross: 74 kg
Notes	Voltage tolerance: 110 V -10% (99 V) / 240 V +10% (264 V) / 380 V -10% (342 V) / 480 V +6% (509 V). Software use subject to Rittal license conditions.
