SK 3359510 TopTherm Blue e Roof-Mounted Cooling Unit Total cooling output 0.77 kW

Giá bán: Liên hệ

SK cooling unit Blue e, roof-mounted, 0.77 kW, 115 V, 1~, 50/60 Hz, Sheet steel, WHD: 597 x 417 x 380 mm

Tình trạng: Còn hàng

Bảo hành:

Địa chỉ

109 Đường N2, Khu dân cư Khang Điền, P. Long Trường, TP HCM, VN

HOTLINE

0917082400

Đặt mua ngay

Thông tin chi tiết
Thông tin bổ sung

CATEGORY	DETAILS
Cooling output	L35/L35: 0.77 kW (50 Hz), 0.78 kW (60 Hz) L35/L50: 0.6 kW (50 Hz), 0.47 kW (60 Hz)
Cooling output (BTU/h)	L35/L35: 2,627 BTU/h (50 Hz), 2,661 BTU/h (60 Hz) L35/L50: 2,047 BTU/h (50 Hz), 1,604 BTU/h (60 Hz)
Rated operating voltage	115 V, 1~, 50/60 Hz
Note	Due to its low noise level, the roof-mounted cooling unit 3273.500 is also suitable for use in office applications.
Rated current max.	6.4 A (50 Hz), 8.4 A (60 Hz)
Start-up current (max.)	18.4 A (50 Hz), 18 A (60 Hz)
Air throughput	External circuit: 910 m³/h (535.6 cfm) Internal circuit: 440 m³/h (259 cfm)
Energy efficiency ratio	EER (L35/L35): 2.14 (50 Hz), 1.86 (60 Hz)
Version	Roof-mounted
Dimensions	597 × 417 × 380 mm
Dimensions (inch)	Width: 23.5˝ Height: 16.4˝ Depth: 15˝
Protection category IP	External circuit: IP 34 Internal circuit: IP 54
Refrigerant / cooling medium	R-513A / 0.4 kg / GWP: 631 / CO₂e: 0.25 t
Refrigerant quantity (lb.)	0.9 lb.
Type of connection (electrical)	Plug-in terminal strip
Duty cycle	100 %
Temperature control	e-Comfort Controller (factory setting +35 °C)
Operating temp range	10 °C to 55 °C (50 °F to 131 °F)
Storage temp range	-40 °C to 70 °C (-40 °F to 158 °F)
Setting range	20 °C to 55 °C (68 °F to 131 °F)
Rated power Pel	L35/L35: 0.36 kW (50 Hz), 0.43 kW (60 Hz) L35/L50: 0.44 kW (50 Hz), 0.48 kW (60 Hz)
Permissible operating pressure	28 bar (406.1 PSI)
Pre-fuse	Transformer circuit-breaker: 11…16 A
Packaging unit	1 pc(s).
Weight	Net: 40 kg Gross: 44.75 kg
